A rubber extruder melt pump (also called rubber melt gear pump) is a positive-displacement precision device installed between the extruder and die, dedicated to high-viscosity, heat-sensitive rubber melt conveying, pressurization, metering and pressure stabilization. It has become an indispensable part of modern rubber extrusion lines.
Operating on the gear meshing principle, the pump draws melt from the extruder into gear cavities, then discharges it at a steady volume and pressure as gears rotate. This design eliminates screw-induced pressure pulsation, controlling die pressure fluctuation within ±1%, greatly improving dimensional consistency of profiles, sheets, hoses and seals.
Key advantages include: First, stable output—flow accuracy reaches ±1%, reducing thickness deviation and scrap rates. Second, efficiency & energy saving—lowering extruder backpressure, cutting energy consumption by 10%–20% and boosting output by 15%–25%. Third, material protection—shortening melt residence time, minimizing thermal degradation for EPDM, NBR, silicone and other rubbers. Fourth, equipment protection—reducing screw axial force to extend extruder service life by 1–2 years.
Built with wear-resistant alloys, electric heating and shaft-end cooling systems, it adapts to high pressure (up to 50MPa) and high viscosity (up to 40,000 Pa·s) working conditions. Optimized flow paths and self-cleaning structures avoid dead zones and material accumulation.
Widely used in automotive rubber parts, sealing strips, hoses, cable sheaths and profile extrusion, the rubber extruder melt pump upgrades product quality, stability and economic benefits for manufacturers.
